AlokTools presents HSS-E High Performance Spiral Point Machine Taps – the ultimate solution for professional threading applications. These premium taps are manufactured from High-Speed Steel with Extra Cobalt (HSS-E), offering exceptional heat resistance and durability for demanding machining operations.
Key Advantages:
✓ Spiral Point Design – Enables efficient chip evacuation for uninterrupted threading
✓ Precision Ground Threads – Ensures accurate, clean-cut threads every time
✓ Extended Tool Life – Cobalt-enhanced composition withstands high temperatures
✓ Wide Size Range – From M3 (0.5mm pitch) to M16 (2mm pitch)
✓ Industrial Applications – Perfect for CNC machining, metal fabrication, and maintenance
| Size | L×L1×D1×A (mm) | CAT No. | PACK QTY. | ||
|---|---|---|---|---|---|
| M16×2 | 102×32×12.5×10 | ATS-8330 | 5 | ||
| M14×2 | 95×30×11.2×9 | ATS-8328 | 5 | ||
| M12×1.75 | 89×29×9×7.1 | ATS-8326 | 5 | ||
| M10×1.5 | 80×24×8×6.3 | ATS-8322 | 5 | ||
| M8x1.25 | 72×22×6.3×5 | ATS-8318 | 10 | ||
| M6×1 | 66×19×6.3×5 | ATS-8317 | 10 | ||
| M5×0.8 | 58×16×5×4 | ATS-8316 | 10 | ||
| M4×0.7 | 53×13×4×3.15 | ATS-8315 | 10 | ||
| M3×0.5 | 48×11×3.15×2.5 | ATS-8314 | 10 |
| Size | M3×0.5, M4×0.7, M5×0.8, M6×1, M8x1.25, M10×1.5, M12×1.75, M14×2, M16×2 |
|---|---|
| L×L1×D1×A (mm) | 48×11×3.15×2.5, 53×13×4×3.15, 58×16×5×4, 66×19×6.3×5, 72×22×6.3×5, 72×22×6.3×5, 80×24×8×6.3, 89×29×9×7.1, 95×30×11.2×9, 102×32×12.5×10 |
| CAT No. | ATS-8314, ATS-8315, ATS-8316, ATS-8317, ATS-8318, ATS-8322, ATS-8326, ATS-8328, ATS-8330 |
| PACK QTY. | 10, 5 |
