AlokTools presents HSS-E Spiral Flute Machine Taps – the professional’s choice for precision threading in blind hole applications. These premium taps feature a high-performance spiral flute design that ensures efficient chip removal, preventing clogging and breakage during operation.
Key Features:
✓ Superior Chip Evacuation – Spiral flute design clears chips upward for blind hole applications
✓ HSS-E Cobalt Construction – 5% cobalt content enhances heat resistance and durability
✓ Precision Ground Threads – For accurate, clean-cut threads in tough materials
✓ Extended Size Range – From M3 (0.5mm pitch) to M20 (2.5mm pitch)
✓ Professional Packaging – 10-piece packs (M3-M8), 5-piece packs (M10-M16), and single pieces (M18-M20)
| Size | L×L1×D1×A (mm) | CAT No. | PACK QTY. | ||
|---|---|---|---|---|---|
| M3×0.5 | 48×11×3.15×2.5 | ATS-8340 | 10 | ||
| M4×0.7 | 53×13×4×3.15 | ATS-8341 | 10 | ||
| M5×0.8 | 58×16×5×4 | ATS-8342 | 10 | ||
| M6×1 | 66×19×6.3×5 | ATS-8343 | 10 | ||
| M8×1.25 | 72×22×6.3×5 | ATS-8345 | 10 | ||
| M10×1.5 | 80×24×8×6.3 | ATS-8348 | 5 | ||
| M12×1.75 | 89×29×9×7.1 | ATS-8352 | 5 | ||
| M14×2 | 95×30×11.2×9 | ATS-8354 | 5 | ||
| M16×2 | 102×32×12.5×10 | ATS-8356 | 5 | ||
| M18×2.5 | 112×37×14×11.2 | ATS-8358 | 5 | ||
| M20×2.5 | 112×37×14×11.2 | ATS-8360 | 1 |
| Size | M3×0.5, M4×0.7, M5×0.8, M6×1, M8×1.25, M10×1.5, M12×1.75, M14×2, M16×2, M18×2.5, M20×2.5 |
|---|---|
| L×L1×D1×A (mm) | 48×11×3.15×2.5, 53×13×4×3.15, 58×16×5×4, 66×19×6.3×5, 72×22×6.3×5, 80×24×8×6.3, 89×29×9×7.1, 95×30×11.2×9, 102×32×12.5×10, 112×37×14×11.2, 112×37×14×11.2 |
| CAT No. | ATS-8340, ATS-8341, ATS-8342, ATS-8343, ATS-8345, ATS-8348, ATS-8352, ATS-8354, ATS-8356, ATS-8358, ATS-8360 |
| PACK QTY. | 10, 5, 1 |
