Anvil-type: RH type available
3/4″SQ.drive model available
Ideal for assembly and maintenance of trucks
Well balanced Ergonomic design
2 Steps throttle for precise control
4 positions regulator
360 free rotating exhaust
| MODEL | Drive (in) | Bolt Size (mm) | Torque Range (kg.m) | Max Torque (kg.m) | Net Weight (kg) | Overall Length (mm) | Center Height (mm) | Free Speed (rpm) | Air Cons Free (m3/min) | Air Cons Load (m3/min) | Air Inlet (PT) | Hose Size (in) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MI-2500P | 1 | 25 | 50-110 | 130 | 8.2 | 265 | 50 | 5300 | 1.2 | 0.7 | 3/8 | 1/2 | ||
| MI-2500GS(ES) | 1 | 25 | 50-110 | 130 | 8.2 | 341 | 50 | 5300 | 1.2 | 0.7 | 3/8 | 1/2 |
| MODEL | MI-2500P, MI-2500GS(ES) |
|---|---|
| Drive (in) | 1, 1 |
| Bolt Size (mm) | 25, 25 |
| Torque Range (kg.m) | 50-110, 50-110 |
| Max Torque (kg.m) | 130, 130 |
| Net Weight (kg) | 8.2, 8.2 |
| Overall Length (mm) | 265, 341 |
| Center Height (mm) | 50, 50 |
| Free Speed (rpm) | 5300, 5300 |
| Air Cons Free (m3/min) | 1.2, 1.2 |
| Air Cons Load (m3/min) | 0.7, 0.7 |
| Air Inlet (PT) | 3/8, 3/8 |
| Hose Size (in) | 1/2, 1/2 |
